Bently Nevada 170180-02-00 External Transducer I/O Module with 2 Independent Channels and 10 kHz Sampling Rate for FieldMonitor Systems

  • 1
  • 2
  • 3

Brand Name : Bently Nevada

Model Number : 170180-02-00

Place of Origin : USA

MOQ : 1

Price : 66USD

Payment Terms : T/T

Supply Ability : in stock

Delivery Time : 2-3 work days

Packaging Details : Brand new and original

Brand : Bently Nevada

Part number : 170180-02-00

Description : External Transducer I/O Module

Estimated Shipping Size : 12.6x2.1x10.5cm

weight : 0.3kg

Shipping : TNT, DHL, FedEx, EMS, UPS

MOQ : 1 piece

Packaging : Original new packaging

Contact Now

Bently Nevada 170180-02-00 External Transducer I/O Module
Product Parameters
Parameter Specification
System Compatibility Bently Nevada 1701 FieldMonitor
Number of Channels 2 (Independent)
Supported Transducers 2-wire Velocity Transducers (e.g., Velomitor)
Input Signal Range 0 to -Vt (Negative voltage)
Sampling Rate 10 kHz per channel
Frequency Response -5% at > 25 kHz
Input Impedance 9.98 ± 0.02 KΩ
Current Draw 2.0 mA max (without transducer)
Power Requirement 24V DC (sourced via Terminal Base)
Key Features
  • Supports two transducer channels, enabling connection of up to two vibration sensors
  • Fully compatible with FieldMonitor terminal bases for seamless system integration
  • Designed with a single-slot structure, allowing space-efficient installation within the FieldMonitor system
  • Provides enhanced vibration monitoring capabilities to improve machine condition analysis and diagnostics
Frequently Asked Questions
What is the main function of this module?
It serves as an interface for your hardware, converting signals from 2-wire velocity transducers into data that the FieldMonitor system can use to monitor vibration on rotating equipment.
Can I use a -01-00 module instead of a -02-00?
No, they are not interchangeable. The -02-00 is specifically designed for 2-wire sensors, while the -01-00 supports different transducer types. Using the incorrect module will result in no signal or inaccurate data.
Do I need to power down the system to replace this module?
Typically no. These modules are designed to be hot-swappable. However, you should temporarily bypass any "Auto-Shutdown" logic associated with that channel to prevent system alarms when removing the module.
What should I do if the "OK" light remains off after installation?
First check your loop wiring. Since this is a 2-wire setup, reversed wires or loose connections are common issues. If wiring is correct and the light remains off, try moving the module to another slot to determine if the issue is with the module or the base.
